Tipping Tipper Hoist "Front Mount" Hydraulic Cylinder 116-3-3195H
Make 4 interest-free payments of $772.99 fortnightly and receive your order now.
In StockTruck Trailer TIPPING HOIST – Front Mount
MAKE: Hidromas
TYPE: Front Mount
MODEL: 116-3-3195H
DETAILS: 116mm diameter of first stage, 3 Stages, 3195mm Stroke
PIVOT CENTRE FOR 48°: 3950mm
TIPPING CAPACITY: 18T
BARREL DIMENSION: 136mm
Dimensions as per attached photo/drawing are:
A. Closed Height including 30mm pullout: 1480mm
C. Centre of bottom trunnion pin to bottom of hoist: 343mm
D. Centre to centre of feet bolt holes: 240mm
E. Maximum width of foot print: 313mm
PORT BSP: ¾”
SWEPT VOLUME: 30 Litres
FOOT HEIGHT: 1 pair x 100mm
Lifting Brackets: Y
(JOT-116-3-3195H)
SKU | JOT-116-3-3195H |
Brand | Hidromas |
Shipping Weight | 170.0000kg |
Shipping Width | 0.600m |
Shipping Height | 1.100m |
Shipping Length | 0.500m |
Shipping Cubic | 0.330000000m3 |
Unit Of Measure | ea |
