Tipping Tipper Hoist "Underbody" Well Mount Hydraulic Cylinder 175-4-6940C

$3,465.00

More info.

Make 4 interest-free payments of $866.25 fortnightly and receive your order now.

In Stock


Calculate Shipping



Free pick-up from store - $0.00
Free pick-up from store

Truck Trailer TIPPING HOIST – Well Mount



EX DEMO STOCK

MAKE:  Hidromas

TYPE:  Well Mount “Underbody”

MODEL:  175-4-6940C

DETAILS:  175mm diameter of first stage, 4 Stages, 6940mm Stroke

PIVOT CENTRE FOR 48°:  8600mm

TIPPING CAPACITY:  45T

BARREL DIMENSION:  197mm

Dimensions as per attached photo/drawing are:

A.    Closed Height including 30mm pullout:  2290mm

B.    Centre of bottom trunnion pin to centre of top clevis pin:  2080mm

C.    Centre of bottom trunnion pin to bottom of hoist:  77.5mm

D.    Centre to centre of feet bolt holes:  343mm

E.    Maximum width of foot print:  380mm

PORT BSP:  1”

SWEPT VOLUME:  123 Litres

FOOT HEIGHT:  1 pair x 125mm

CLEVIS:  2



(NET-175-4-6940C)

SKU NET-175-4-6940C
Brand Hidromas
Shipping Weight 335.0000kg
Shipping Width 0.400m
Shipping Height 2.080m
Shipping Length 0.400m
Shipping Cubic 0.332800000m3
Unit Of Measure ea
