Tipping Tipper Hoist "Underbody" Well Mount Hydraulic Cylinder 197-5-6200C
More infoMake 4 interest-free payments of $1,206.25 fortnightly and receive your order now.
In StockTruck Trailer TIPPING HOIST – Well Mount
MAKE: Hidromas
TYPE: Well Mount “Underbody”
MODEL: 197-5-6200C
DETAILS: 197mm diameter of first stage, 5 Stages, 6200mm Stroke
PIVOT CENTRE FOR 48°: 7700mm
TIPPING CAPACITY: 50T
BARREL DIMENSION: 220mm
Dimensions as per attached photo/drawing are:
A. Closed Height including 30mm pullout: 1760mm
B. Centre of bottom trunnion pin to centre of top clevis pin: 1520mm
C. Centre of bottom trunnion pin to bottom of hoist: 90mm
D. Centre to centre of feet bolt holes: 343mm
E. Maximum width of foot print: 425mm
PORT BSP: 1”
SWEPT VOLUME: 126 Litres
FOOT HEIGHT: 1 pair x 150mm
CLEVIS: 3
(JOT-197-5-6200C)
| SKU | JOT-197-5-6200C |
| Brand | Hidromas |
| Shipping Weight | 330.0000kg |
| Shipping Width | 0.600m |
| Shipping Height | 1.100m |
| Shipping Length | 0.500m |
| Shipping Cubic | 0.330000000m3 |
| Unit Of Measure | ea |
